FAN7380MX Half-Bridge MOSFET & IGBT Gate Driver IC | SOP-8

FAN7380MX half-bridge gate driver IC for repairing compatible switching power supplies and electronic equipment. Designed to drive high-side and low-side MOSFETs and IGBTs, this component supports bootstrap operation up to 600V in a compact 8-pin surface-mount package.

Product details
• Part number: FAN7380MX
• Type: Half-bridge gate driver IC
• Package: SOP-8 / SOIC-8 surface mount
• Application: MOSFET and IGBT gate control
• High-side bootstrap voltage: Up to 600V
• Quantity: 1 chip

Match the part number, package and circuit requirements to your original component before ordering. Installation requires surface-mount soldering skills.

JBL EON 515XT Power Supply Repair Example
